7 Inch LCD Display with USB Port Medicine Stability Test Chamber
Biobase Meihua Trading Co., Ltd.- After-sales Service：Online
- Power Supply：220,110
- Certification：ISO
- Warranty：1 Year
- Capacity：120L
- Display：7′ LCD
Base Info
- Model NO.：BJPX-MS288A
- Temperature Range：-20~65c
- Humidity：40-95%Rh
- Shelf：2 PCS
- Refrigerant：R134A
- Transport Package：Carton Package
- Specification：930*600*1500MM
- Trademark：BIOBASE
- Origin：China
- Production Capacity：1000,Month
Description
Model
BJPX-MS120A
BJPX-MS 288A
BJPX-MS 500A
Display
7' LCD
Capacity
120L
288L
500L
Temp. Range
-20~65°C
Temp.Fluctuation
± 0.5°C
Temp.Uniformity
± 2°C
Humidity Control Range
40~95% RH (Natural evaporation, no humidifier)
Humidity Fluctuation
±3% RH
Illuminationation
4500 ± 500Lux,4 level adjustable ,1-side illumination
Shelves
2 pcs adjustable
Timing Range
1~99 hour each section
Refrigeration System
2 sets auto-shift compressor ,R134a refrigerant
Consumption
2000W
2500W
3000W
Power Supply
AC220V±10%,50HZ/60HZ
Chamber Size(W*D*H)
450*450*600mm
600*600*800mm
700*800*900mm
External Size (W*D*H)
600*930*1590mm
750*1010*1770mm
850*1210*1870mm
Packing Size(W*D*H)
750*1080*1760mm
950*1160*1940mm
1000*1460*2050mm
Gross Weight
138kg
168kg
250kg
Safety System
Chamber temperature protection, Compressor over current and overpressure protection, Water shortage protection, Heater over temperature protection, Alarm with noise and light if any abnormities.
Optional
UV disinfection system
