Clutch Cover Automatic Balancing Machine Automated Clutch Pressure Plate Balance
Shanghai Jianping Dynamic Balancing Machine Manufacturing Co., Ltd.- Warranty：1 Year
- Max Diameter of Workpiece：<500mm
Base Info
- Model NO.：A1LZ1
- Mass Scope of Workpiece：<900kg
- Type：Balancing Machine
- Accuracy Grade：0.5
- Load Way：Electronic Load
- Loading Method：Static Load
- Display：Needle
- Control：Computer Control
- Weight：100-500Kg
- Power Source：AC380V
- Oil Cylinder Position：Top
- Transport Package：Standard Export Wooden Box
- Specification：ISO. CE. SGS CNAS
- Trademark：JP
- Origin：Shanghai China
- HS Code：903110009
- Production Capacity：100 Sets,Month
- Package size per unit product：1800.00cm * 2100.00cm * 1630.00cm
- Gross weight per unit product：1058.000kg
Description
Sr.no.
Specification
Parameter
1
Max. Weight of Workpiece (kg)
5kg
2
Max. Diameter of Workpiece(A)
200mm
3
Balancing Speed
≤800r/min
4
Balancing Motor Power
2kW(servo motor)
5
Min. Achievable Residual Unbalance
≤1g.mm/kg
6
Measuring time
12-15S
7
Unbalance Reduction Ratio
≥90%
8
Operating Air Pressure
0.4~0.6MPa
9
Operating Voltage
AC:380V external connection
10
Milling Motor Power
3kW
11
Machine Total Power
9kW
12
Protection
Phase sequence protection, overload protection, air pressure monitoring
