Turbocharger Rotation Testing Device, Belt Drived, Vibration Eliminate, Aging Prolonged
Shanghai Jianping Dynamic Balancing Machine Manufacturing Co., Ltd.- Warranty:1 Year
- Type:Vibration Testing Machine
Base Info
- Maxcapacity:<1000KN
- Loading Method:Dynamic Load
- Display:Digital
- Control:Computer Control
- Weight:0-100Kg
- Power Source:AC220V
- Length:900mm
- Width:700mm
- Height:1200mm
- Number of Package:1 Pieces
- Colour:Jp Standard or Custom
- Delivery:Within 15 Days
- Transport Package:Fumigated Wood Box
- Specification:ISO9001: 2008 CE SGS
- Trademark:Jp
- Origin:Shanghai China
- HS Code:90311000
- Production Capacity:1000 Sets,Month
- Package size per unit product:95.00cm * 95.00cm * 163.00cm
- Gross weight per unit product:258.000kg
Description
Basic Info.
Maxcapacity <1000KN Loading Method Dynamic Load Display Digital Control Computer Control Weight 0-100Kg Power Source AC220V Length 900mm Width 700mm Height 1200mm Number of Package 1 Pieces Colour Jp Standard or Custom Delivery Within 15 Days Transport Package Fumigated Wood Box Specification ISO9001: 2008 CE SGS Trademark Jp Origin Shanghai China HS Code 90311000 Production Capacity 1000 Sets/MonthPackaging & Delivery
Package size per unit product 95.00cm * 95.00cm * 163.00cm Gross weight per unit product 258.000kgProduct Description
Armatures dynamic balance machine PHQ-5AUniversally applicable
High balancing accuracy
Easy upgrading through modular structure and a wide range of accessories
Hard-bearing principle ensures fast change-over
JP-580 measuring instrument, with extensive operator prompting
Full range of safety equipment for all protection classes
Production Description
Specially designed brackets transmit mechanical force with low vibration damping
Durable and reliable sensor possesses good linearity
Permanent calibration brings high accuracy with a permission of large initial unbalance amount
Belt-driving offers higher precision and easier operation
Advanced electrical measuring system and friendly man-machine interface
Modular design offers a wide range of application
Range of Application
This balancing machine is widely used in balancing rotatable bodies, such as kinds of medium-sized and small-sized motors rotors, impeller, fans, crankshaft, turbocharger, water pump, roller, grinding wheel, main shaft of machine tool , textile machinery, tool , spindle, etc .. Driven by belt, equipped with Variable speed motor to drive .Which ensures high quality balancing and precision. quick booting ,easy operation. and high efficiency
Special Features
The measuring unit employs JP-580 Electrical Measuring unit is a system of top function and precision. It can be applied in all kinds of single/double plate and hard/soft bearing machines, and can be connected with different velocity and pressure sensors easily. The unit adopts industrial computer made in Yanhua Industry Co, which equiped with 17-inch LCD screen and Windows 7 Operating System. Featuring with high running speed and reliabilitystrong dustproof and shakeproof ability, it is applicable to various industrial environments
Production Parameters
Technical data at a glance | PHQ-1.6A | PHQ-5A | PHQ-16A |
Max Mass of Workpiece (kg) | 1.6 | 5 | 16 |
Max Diameter of Workpiece (mm) | 300 | 300 | 300 |
Distance between Two Support Bearings (mm) | 60-500 | 60-500 | 60-500 |
Journal Diameter Scope of Workpiece (mm) | 3-40 | 3-40 | 5-40 |
Diameter Scope of Driving Belt (mm) | 15-150 | 15-150 | 15-150 |
Rotation Speed when the Diameter of Driving Belt is 100mm (r/min) | 1470 | 1470 | 1470 |
Motor Power (kw) | 0.23DC | 0.23DC | 0.23DC |
Min Achievable Residual Unbalance Amount(emar) | 0.3g. mm/kg | 0.3g. mm/kg | 0.3g. mm/kg |
