High Current Impulse Generator 400 Kv / 30 Kj for Impact Testing
Sansion Power Electric Co., Ltd.- Max Diameter of Workpiece:900mm
- Mass Scope of Workpiece:<900kg
- Type:Impact Testing Machine
- Maxcapacity:>1000KN
- Accuracy Grade:0.5
- Load Way:Electronic Load
Base Info
- Model NO.:SXCF
- Loading Method:Static Load
- Display:LCD
- Control:Computer Control
- Weight:100-500Kg
- Power Source:AC 110V,220V at Customized
- Oil Cylinder Position:Under
- AC Withstand Test for:0~220kv
- Max. Capacity:2000kVA
- Output Frequency:45 - 300Hz
- Waveform:Pure Sine Wave
- Frequency Adjustment Sensitivity:0.01Hz
- Transport Package:Plywood Case
- Specification:ISO9001 SGS
- Trademark:Sansion
- Origin:Wuhan, China
- HS Code:9030339000
- Production Capacity:100 Units
Description
Basic Info.
Model NO. SXCF Loading Method Static Load Display LCD Control Computer Control Weight 100-500Kg Power Source AC 110V/220V at Customized Oil Cylinder Position Under AC Withstand Test for 0~220kv Max. Capacity 2000kVA Output Frequency 45 - 300Hz Waveform Pure Sine Wave Frequency Adjustment Sensitivity 0.01Hz Transport Package Plywood Case Specification ISO9001 SGS Trademark Sansion Origin Wuhan, China HS Code 9030339000 Production Capacity 100 UnitsProduct Description
High Current Pulse Generator 400 KV / 30 KJ For Impact Testing
General Information:
The impulse voltage test system is used for carrying out standard lightning impulse voltage full wave and operation wave tests on High voltage apparatus such as power capacitors, CT/PT, clearance, power transformers, and bushings.
Main Parameters for System
Nominal voltage: ±200kV
Impulse capacitance: 0.5µF
Number of stages: 2
Rated stage voltage: ±100kV
Rated energy: 10kJ
Rated stage capacitance: 1µF(each impulse capacitor 1µF at 100kV, total 2pcs)
