2"or 50mm Brass Three Gang Test Molds

Zhuozhou Tianpeng Imp. & Exp. Trade Co., Ltd.
  • Prouduct Name：Brass Three Gang Test Molds
  • Transport Package：Wooden Case
  • Specification：Brass 2" and 50mm
  • Trademark：C-TECH
  • Origin：China

Base Info

  • Model NO.：PM-BS50
  • HS Code：848060
  • Production Capacity：1000,Month

Description

Basic Info.

Model NO. PM-BS50 HS Code 848060 Production Capacity 1000/Month

Product Description

DESCRITION:

Three gang cube mould

Machined out of High lead naval brass, this three gang 2" x 2" cube mould makes 3 compression test cubes at a time. This mould casts cubes in a diagonal arrangement with a detachable brass base plate.
Wing nut clamps lock the mould to the base while stainless thumbscrews secure halves tightly together.Large screed off upper surface area makes this mold a preferred choice. Optional accessories include an all brass fitted top, or a cover plate designed to pour molten sulfur capping compound down through taper holes for testing compressive strength.



 SPECIFICTION:

Model No                            Dimension(mm)                           Weight(kg)
PM-BS50                          2" x 2" cube mould                                     8.4
EL39-0410                        50×50 cube mould                                     6.5
