CNC Automatic 3D Image Measurement Machine

Guangzhou Minder-Hightech Co., Ltd.
  • Max Diameter of Workpiece：760mm
  • Mass Scope of Workpiece：<900kg
  • Type：Universal Testing Machine
  • Maxcapacity：<1000KN
  • Accuracy Grade：0.5
  • Load Way：Electronic Load

Base Info

  • Model NO.：JTVMS-6050CNC
  • Loading Method：Dynamic Load
  • Display：Digital
  • Control：Computer Control
  • Weight：100-500Kg
  • Power Source：180V-260V(AC)
  • Transport Package：Wooden Box
  • Specification：1840-960-1867(mm)
  • Trademark：Minderhightech
  • Origin：Guangzhou-Guangdong
  • HS Code：9031499090
  • Production Capacity：100 Pieces,Mouth

Description

 X,Y-motor speed<120MM/S   Z-motor speed<60 MM/S
Motor motion step length 0.4 MM/step         motor resolution1000step/turn

Instrument advantages
The CNC Automatic 3D Video measurement machine compare with Similar products have some advantages:
  1. CNC Electric desktop
  2. CNC Automatic measurement
  3. SPC Data conversion
  4. Auto focus
  5. Graphics output to Auto CAD
  6. Graphics output to Auto CAD and automatically correct
  7. Auto CAD standard drawing input
  8. JPEG input
  9. Custom circle, line segments and draw directly
  10. Coordinate labeling
  11. Measurement, and drawing
  12. Map photo
  13. The measured data can be imported into a specified form such as Excel and other proprietary formats
