• Model NO.：GDH-100
• Power Source：AC 85V-265V
• Weight：0-10Kg
• Installation：Direct Connected
• Customized：Customized
• Testing Current：DC 0-100A.
• Max. Ripple Ratio：3% @ 100A, 20milliohm
• Measure Range：0~1.999milliohm , 0~19.99milliohm.
• Resolution：1microohm , 10microohm
• Accuracy：1.0%
• Power Supply：AC 220V+-20%, 50Hz+-1
• Dimension：36*27*30cm
• Transport Package：Wooden Case
• Specification：ISO, SGS
• Trademark：HV Hipot
• Origin：Wuhan China
• HS Code：9030899090
• Production Capacity：2000PCS,Year

Basic Info.

Model NO. GDH-100 Power Source AC 85V-265V Weight 0-10Kg Installation Direct Connected Customized Customized Testing Current DC 0-100A. Max. Ripple Ratio 3% @ 100A, 20milliohm Measure Range 0~1.999milliohm / 0~19.99milliohm. Resolution 1microohm / 10microohm Accuracy 1.0% Power Supply AC 220V+-20%, 50Hz+-1 Dimension 36*27*30cm Transport Package Wooden Case Specification ISO, SGS Trademark HV Hipot Origin Wuhan China HS Code 9030899090 Production Capacity 2000PCS/Year

Product Description

DC 100A Circuit Breaker Contact Resistance Tester (Manual Type)

GDH-100 Contact Resistance Tester is designed to measure circuit loop resistance(contact resistance) of high/low voltage switchgear, power cable and wires, and weld joint.


Features

1. Four leads measurement method, high accuracy.
2. Adjustable testing current and low ripple.
3. Two 31/2 LED windows to display Current and Resistance.
4. Over-current and Over-heat protection.
5. Easy to operate.
6. Portable, high precision.


Specifications


Testing current	DC 0-100A
Max. Ripple ratio	3% @ 100A, 20milliohm
Measure range	0~1.999milliohm / 0~19.99milliohm
Resolution	1microohm / 10microohm
Accuracy	1.0%
Power supply	AC 220V+-20%, 50Hz+-1
Operation conditions	0 to 40degree, RH<85%
Dimension	36*27*30cm
Weight	7.5kg

Packing list


GDH-100 Instrument	1pc
Carrying Bag	1pc
Test Leads	2pcs
Power Cord	1pc
Spare Fuse	2pcs
GDH-100 Manual	1pc
Calibration Certificate	1pc
Quality Certificate	1pc
Warranty Card	1pc
