Test Instrument

Simulated Environmental Chamber China Manufacturer Test Chamber

Guangdong Komeg Industrial Co., Ltd.
  • After-sales Service:24 Hours on Line Services
  • Warranty:12 Months
  • Type:Material Testing Machine
  • Weight:100-500Kg
  • Power Source:AC380V
  • Temp. Range:-20°c~+150°c or -68°f~+302°f

Base Info

  • Model NO.:KMH-408S
  • Color:Blue & Grey
  • Equipment Power:10.6kw
  • Interrior Material:700*750*800mm
  • Exterrior Material:980*1940*1740mm
  • Weight(Kg):450kg
  • Humidity Range:20-98%R.H.
  • Heat up Time:-70oc~+100oc Within 60mins
  • Pull Down Time:+20oc~-70oc Within 80mins
  • Humidity Uniformity:+,-3.0%R.H.
  • Transport Package:Strong Plywood Case, Meet International Standard
  • Specification:Standard and Customized
  • Trademark:KOMEG
  • Origin:Dongguan, P. R. China
  • HS Code:90321000
  • Production Capacity:1000 Sets,Year

Description

Environmental Temperature and Humidity ChamberSecifications ( at +20°C  room temp.  Or+25°C  water temp with empty load)ModelKMH-S series225S408S800S1000SInterior sizelW(mm)70070010001000H(mm)70075010001000D(mm)4808008001000Exterior sizeW(mm)98098012801280H(mm)1890194021602160D(mm)1460174017501950Weight(KG)330450550650Temp. range -70 °C ~+150°C Humidity Range20 ~ 98&R.H.Temp. constancy±0.5ºC   Humidity constancy±2.5%R.HHumidity uniformity±3.0%R.H±5.0 % R.HHeat up time -70°C  ~ +100°C , within 60 minPull down time +20°C  ~ -70°C  , within 80 minEquipment Power9.5KW10.6KW18.5KW18.5KWAmbient Temp.5ºC  ~+35ºC  Standard accessoriesSight window*1,  cable port(portΦ50mm)*1,   shelves*2,    chamber lamp*1,    power cable *2mSafety device  (standard)No fuse breaker, over pressure over heat and over current protection for compressor,
Over temp. protect, over load protect of blower, dry heat protection
Control SystemBalanced Temperature & Humidity Control SystemRefrigeration systemAir Cooled (Water Cooled Type is option)Hermetic compressor,Cascsde Refrigeration
CFC-Free refrigerant(HFC-507/HFC-23)
ControllerPanel:7-inch LCD Touch panel,    Chinese or English display selectableOperation model :Program or fix point runningMemory capacity :120programs,1200steps,All repeat 999 cycles, part repeat 99 cyclesInterior materialStainless Steel Plate ( SUS 304 )Exterior materialBaked Painting Steel Or Stainless steel(SUS304)Insulation materialRigid polyurethane Foam and Glass Fiber WoolSystemBalanced & Humidity Control SystemWiring methodAC 380±10 %  50Hz ,3 phase 4 wires +Ground WiresNote: 1. We reserve the right to change specifications without prior notice
           2. Customized sizes and configurations available
