Leakage Current Test Zinc Oxide Lightning Arrester Characteristic Tester (GDYZ-301A)
HV Hipot Electric Co., Ltd.- Use condition：-20ºC ~ 50ºC, RH<80%
- Charging power supply：AC 220V±10%
- Input range of PT reference voltage：0 ~ 300V
- Input resistance of voltage channel：≥150KΩ (with fuse)
- Measuring accuracy of PT reference volta：±(2% of the reading+0.5V)
- Measuring range of current input：0-10mA
Base Info
- Model NO.：GDYZ-301A
- Measurement accuracy of current fundamen：±(2% of the reading+5μA)
- Measurement accuracy of current harmonic：±(5% of the reading+10μA)
- Input resistance of current channel：≤1Ω
- Action times of monitor：0 ~ 99 times
- 8/20μS impulse current：≥50Ap
- Calibration range of current meter：0 ~ 10mA
- Calibration accuracy of current meter：±(2% of the reading+5μA)
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan China
- HS Code：9030820000
- Production Capacity：2000PCS,Year
Description
4kg (without accessories)
