• Model NO.：SX-3000
• Control：Manual Control
• Weight：0-100Kg
• Power Source：AC 110V,220V at Customized
• Oil Cylinder Position：Under
• Vacuum Degree Measuring Range：10-5~10-1PA
• Humidity：0-80%
• Transport Package：Plywood Case
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9030820000
• Production Capacity：100 Units

Basic Info.

Model NO. SX-3000 Control Manual Control Weight 0-100Kg Power Source AC 110V/220V at Customized Oil Cylinder Position Under Vacuum Degree Measuring Range 10-5~10-1PA Humidity 0-80% Transport Package Plywood Case Specification ISO9001 SGS Trademark Sansion Origin Wuhan, China HS Code 9030820000 Production Capacity 100 Units

Product Description

General Information:
Also called VCB Vacuum Degree Tester, Vacuum Degree Analyzer, VCB Analyzer, Circuit Breaker Interrupter Vacuum Degree Tester
SX-3000 Vacuum Circuit Breaker Tester is designed to measure the vacuum degree of vacuum interrupter. It's the essential instrument for manufacturer, installation, commission, maintenance of circuit breaker.

Features:
√   To measure quantitatively on vacuum degree of various vacuum switches interrupters.
√   To measure the vacuum interrupter without dismounting.
√   Test result is accurate and reliable.
√   LCD English display, easy to operate.
√   RS232 port, can communicate with computer easily.
√   Light weight and portable, it's suitable for on-site test.

Specification:√  Power supply: AC220V+15%, 50Hz
√  Vacuum degree measuring range: 10-5~10-1Pa
√  Electrical field voltage: 20kV
√  Magnetic field voltage: 1600V
√  Measuring precision:   10-5~10-4 Pa, 20%-25%
                         10-4~10-3 Pa, 15%-20%
                         10-3~10-2 Pa, 10%-15%
                         10-2~10-1 Pa, 5%-10%
√  Allowed environmental temperature: -10ºC~40ºC
√  Humidity: ≤80%RH
√  Oversize:460×335×330(mm)
√  Test unit weight: 12kg

Please contact with us for further information, our  technically expereinced expertise team will select correctly designed test set for you.

Warranty: One year quality guarantee after shipment.
