• Model NO.：SXFA-II
• Loading Method：Dynamic Load
• Display：LCD
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC 110V,220V at Customized
• Oil Cylinder Position：Under
• Output：0~1000V(20A Peak Value)
• Test 1 CT PT：Volt-Ampere Characteristic(Excitation) Curve
• Test 2 CT PT：Auto Calculates Knee Point Value
• Test 3 CT：5%and 10% Error Curve
• Test 4 CT PT：Turns Ratio
• Test 5 CT PT：Polarity
• Test 6 CT：Primary Flow Injection
• Test 7 CT PT：AC Withstand Test
• Test 8 PT：Iron Core Demagnetization
• Test 9 CT：Demagnetization
• Transport Package：Plywood Case
• Specification：ISO9001 SGS
• Trademark：Sansion
• Origin：Wuhan, China
• HS Code：9030339000
• Production Capacity：100 Units

CTPTVolt-ampere characteristic(excitation) curveVolt-ampere characteristic(excitation) curveAuto calculates knee point valueAuto calculates knee point value5%and 10% error curveTurns ratioTurns ratioPolarityPolarityAC withstand testPrimary flow injectionIron Core DemagnetizationAC withstand test Demagnetization
 Working supplyAC220V±10% , 50HzOutput0~1000V(20A peak value)Current Output0~600AExcitation Measuring Precision≤0.5%(0.2%*read+0.3%*range)CT
Turns RatioRange≤5000A/1A(25000A/5A)Precision≤0.5%PT
Turns RatioRange1KV~500KVPrecision≤0.5%Working EnvironmentTemperature: -10ºC ~ 40ºC,Humidity: ≤90%,Altitude: ≤1000mSize and Weight400mm × 250mm × 250mm,  Weight≤22Kg More information, please kindly contact with us, we can customize the suitable test set according your requirements and give you the best quotation. Thank you!
