Portable GDPQ-300M Power Quality Analyzer Power Logger
HV Hipot Electric Co., Ltd.- Type：Universal Testing Machine
- Accuracy Grade：0.5
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
- Control：Computer Control
Base Info
- Model NO.：GDPQ-300M
- Weight：0-100Kg
- Power Source：AC220V
- Error of fundamental voltage：+,-0.2%
- Error of voltage deviation：+,-0.2%
- Error of fundamental current：+,-0.5%
- Transport Package：Standard Plywood Case
- Specification：ISO9001
- Trademark：HV Hipot
- Origin：Wuhan, China
Description
≤±5°
or h×±1Ih<3%IN 0.15%IN
b. Measurement range of instrument of class A: 0~2500Hz, used for accurate measurement. Measured phase error is less than ±5° or ±1×h°.
7) Inter-harmonics: the requirement is the same as harmonics.
Electrical parameters
1) Power supply: AC 220V±10%; 50Hz±0.5Hz; harmonic distortion≤15%
2) Current signal input
3) Voltage signal input
Use conditions
or h×±1
b. Measurement range of instrument of class A: 0~2500Hz, used for accurate measurement. Measured phase error is less than ±5° or ±1×h°.
7) Inter-harmonics: the requirement is the same as harmonics.
Electrical parameters
1) Power supply: AC 220V±10%; 50Hz±0.5Hz; harmonic distortion≤15%
2) Current signal input
- Rated value In: 5A, 60A/600A/600A (1pc flexible probe is optional)
- Measurement range: AC10mA~6A, 10mA~6000A (1pc flexible probe is optional)
- Power consumption: ≤0.5VA/channel
- Overload capacity: 1.2In, continuously working; 2In 1s is allowable
3) Voltage signal input
- Rated value Un: 57.7V/100V, 220V/380V(customized), 400V/690V;
- Measurement range: AC 0.5V~120V, 0.5V~450V(customized); 0.5V~1000V(customized)
- Power consumption: ≤0.5VA/channel
- Overload capacity: 1.3Un, continuously working; 1.4Un, 1s is allowable
Use conditions
- Normal working temperature: -10ºC~+55ºC
- Working temperature limit: -20ºC~+65ºC
- Relative humidity: 5%~95%
- Protection class: IP50
