0.5kn Digital Display Single Column PVC Tension Tester
Jinan Kason Testing Equipment Co., Ltd.- After-sales Service：24 Hours Technical Supply
- Warranty：12 Months
- Max Diameter of Workpiece：<500mm
- Mass Scope of Workpiece：<900kg
- Type：Tensile Testing Machine
- Maxcapacity：500n
Base Info
- Model NO.：WDS-05
- Accuracy Grade：1
- Load Way：Electronic Load
- Loading Method：Static Load
- Display：Digital
- Control：Manual Control
- Weight：100-500Kg
- Power Source：AC220V
- Oil Cylinder Position：No
- Certification：ISO CE
- Transport Package：Plywood Exporting Package
- Specification：120kg 0.8CBM
- Trademark：HST
- Origin：Jinan, Shandong, China
- HS Code：9024101000
- Production Capacity：1500 Sets,Month
Description
Single column double spacesControl method Single chip control Load accuracy 1 class Load range 2%~100%F·S/0.4%-100% FS Displacement Resolution 0.01mm Test speed 1-500mm/min(can be customized) Tensile space 600mm (can be customized) Compression space 600mm(can be customized) Power supply AC220V±10%,50Hz(can be customized) Grips Wedge type, plate type and other grips as consumer's demand Dimension 425*400*1315mm Weight 90kg
4. Main Unit Feature:
4.1 Adopt single column structure, lower for tensile, upper for compression, double space. The beam is step less lifting, light but rigid.
4.2 Adopting ball screw drive, realize no clearance transmission,make sure the precision control of the test force and deformation speed.
4.3 The photoelectric encoder is the displacement sensor, with high resolution, strong anti-interference ability.
4.4 The shield plate with limit mechanism used to control the beam moving range, in order to avoid sensor damaged due to the moving distance is too large.
4.5 The table, moving beams is made of high quality precision machining steel plate , not only reduce the vibration generated by specimen fracture, but also improve the stiffness.
4.6 The motor tail is upwards, above the work surface, this design makes the main unit lower space narrowing, the whole machine is more coordinating, and more easy to spread out the heat generated by the motor rotation, extend electrical components life.
4.7 Three columns of mandatory orientation, make the main unit rigidity much improved, to further ensure the repeatability of measurement.
4.8 Adopt bolt type grip installation, make the grip replace easier.
5. Function Feature:
5.1 Automatic calibration: system can automatically realize the accuracy of the calibration value.
5.2 After the sample broken, automatic stop.
5.3 Automatic display: During the whole testing process, the LCD real-time display the testing force,peak value, displacement, testing speed and testing force-time curve,testing force-displacement curve.
5.4 Automatic return: beam automatic return to initial position when testing finished.
5.5 Breakage judgment: sample after fracture,beam automatic stop moving.
5.6 Limiting protection: Program control and Mechanical limiting protection.
5.7 Overload protection: When more than 3 ~ 5% of the rated load device automatically stop working.
5.8 Automatic calculation: automatic calculation area after input sample diameter (round); Width, thickness (flat), sample gauge ect.
