Electronic Film Elongation Tensile Testing Instrument
Dongguan Haida Equipment Co., Ltd.- Type：Tensile Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：0.5
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Computer Display, Digital
Base Info
- Model NO.：HD-609A-S
- Control：Computer Control
- Weight：0-100Kg
- Power Source：AC220V
- Standards：ASTM JIS Cns Pstc
- Motor：Panasonic Servo Motor
- Warranty：One Year
- Delivery Time：15 Days After Receive The Deposit
- Elongation Accuracy：0.001mm
- Load Cell：Celtron Sensor
- Load Resolution：1,250, 000
- Screw：High Precise Ball Screw
- Stroke：1000mm
- Transport Package：Strong Plywood Case
- Specification：Design Standards: GB,T16491; GB,T1040; GB,T1041; G
- Trademark：Haida
- Origin：Dongguan, China
- HS Code：9024109000
- Production Capacity：150 Sets Per Month
Description
Features of Film Elongation Tensile Tester:
1. Motor system: Panasonic servo motor +Servo driver +High precise ball screw (Taiwan).
2. Control system: a, computer control with TM2101 software; b, Back to origin automatically after the test, c, store data automatically or by manual operation.
3. Data transmission: RS232.
4. Displacement resolution: 0.001mm.
5. Graph scale automatic optimization can make graph to display with best measurement and can implement graphics dynamic switching in the test and has force-elongation, force- time, elongation -time, stress - strain.
6. It can save results automatically after test finished, and it is manual filing. It can display maximum force, yield strength, compressive strength, tensile strength, elongation, peel interval maximum, minimum and average, etc.
7. User can set parameters of product material such as length, width, thickness, radius, area and so on.
8. Many languages random switching: Simplified Chinese, Traditional Chinese, and English.
