0~16kV Cable fault locator (GD-2136L)
HV Hipot Electric Co., Ltd.- Certification：ISO9001
- Customized：Customized
- Max. testing distance：32km
- Non-detection zone：1m
- Power consumption：5VA
- Location testing accuracy：less than 10cm
Base Info
- Model NO.：GD-2136L
- Cable depth：less than 3m
- Output Voltage：DC 0~16kV adjustable
- Transport Package：Wooden Case
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：China
- HS Code：9030332000
- Production Capacity：1000PCS,Year
Description
GD-2132 Cable Fault Locator
Including transmitter, receiver, Inductive probe, potential type detection frame. It is suitable to test all kinds of power cable with metallic conductor.
Its main function is locating poor insulation point, detecting circuit and depth of power cable.
Features
l High sensitivity
l Low static drift
l High accuracy of locating
l Anti-interference
l LCD screen to show signal and status
l Built-in rechargeable Li-battery.
Specifications
GD-2133 Cable Fault Detector
It can test faults of short circuit, grounding, high impedance leakage, high impedance flashover fault and cable's poor connection, disconnection for all kinds of power cables (voltage degree 1kV-35kV), local cable, communication cable, coaxial-cable and metal overhead line. It also can measure cable's length and propagation speed of electric wave speed on the cable.
Features
l Safe, prompt and accurate testing. It uses LV impulse method and HV flashover detection, which test all kinds of cable faults.
l Using high speed data sampling technology. A/D sampling speed is 100Mhz.
l Wave form and data automatically display on big LCD screen.
l Wave form and parameter storage function.
l Function of comparing testing waveform of cable fault with normal waveform.
l Wave form extending function.
l Directly show fault point and testing point direct distance or relative distance.
l Modify speed of propagation any time according to different testing cables.
l Built-in rechargeable battery. Small size, portable to carry.
Specifications
