Gd-V Automatic Transformer Capacity Tester

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Description：Gd-V Automatic Transformer Capacity Tester
  • Application：Test Capacity, on-Load Loss of Power Transformer
  • Function：Test on-Load Loss, No Load Loss of Transformer
  • Measurement Range of Capacity：30kVA - 65000kVA
  • Features：Small in Volume, Light in Weight, in High Accuracy
  • Dimension：400mm*300mm*220mm

Base Info

  • Model NO.：GD-V
  • Weight：12kg
  • Display：Digital Display
  • Power Supply：220V, 50Hz
  • Warraty：1 Year
  • Transport Package：Packed in Veneer Case
  • Specification：57*45*33cm, 20kg
  • Trademark：GOLD
  • Origin：China, Chongqing
  • HS Code：9031809090
  • Production Capacity：1000 Sets , Month

Description

Basic Info.

Model NO. GD-V Weight 12kg Display Digital Display Power Supply 220V, 50Hz Warraty 1 Year Transport Package Packed in Veneer Case Specification 57*45*33cm, 20kg Trademark GOLD Origin China, Chongqing HS Code 9031809090 Production Capacity 1000 Sets / Month

Product Description

GD-V Automatic Transformer Capacity Tester

Introduction:

  • GD-V Automatic Transformer Capacity Tester can test the transformer capacity, type, on-load current, on-load loss, short circuit (load) loss, resistance voltage, etc.It is small in volume, light in weight, in high accuracy, with steady property, easy to operation can replace the traditional testers.
  • GD-V Automatic Transformer Capacity Tester is displayed by LCD, operated by menu, with friendly interface, is the first choice for all customers.


Specifications:

Item NameGD-V Automatic Transformer Capacity Tester
Measurement range of capacity30KVA~65000KVA
AccuracyVoltage: 0-100V, ±0.2%FS; 100-700V, ±0.2%
current: 0-10A, ±0.2%FS; 10-100A, ±0.2%
power: ±0.5%(CosΦ>0.1), ±1.0%(0.02< CosΦ< 0.1)
Dielectric strengthInsulating resistance of voltage, current input terminal to case≥100MΩ;
Input terminal of the working power can stand 2kV (RMS) to case, time is one minute
Service conditionTemperature: -5ºC~40ºC
Humidity: < 95%(25ºC)
Altitude: < 2500m
External disturbance: no extra-heavy shock, no extra-heavy electromagnetic field
External power supply: 220V±10%, 45Hz~55Hz
Dimension400mm*300mm*220mm
Weight12kg


Features:

  1. Can accurately test the capacity for all kinds of customers, convenient and accurate.
  2. The device auto-switch the measurement range, wide range for voltage, current test, easy to connect wire.
  3. All test results can be auto calibrated. It can calibrate following: wave form, temperature, non-rated voltage, non-rated current, so improve the accuracy.
  4. 320x240 LCD, friendly man-machine interface, brilliance control, adapts to all seasons.
  5. Panel type printer can print the test results on site.
