Loss on Heating ASTM D6 ASTM D1754 Tfot Thin Film Oven for Asphaltic Materials
Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.- Loss on Heating：Loss on Heating , Thin Film Test
- Thin Film Oven：Loss on Heating Oven (Tfot)
- Reference Standard：ASTM D1754, ASTM D6
- Warranty：1 Year
- Transport Package：Plywood
- Trademark：GOLD
Base Info
- Model NO.：GD-0609
- Origin：Made in China
- HS Code：9031809090
- Production Capacity：100sets,Month
Description
Basic Info.
Model NO. GD-0609 Origin Made in China HS Code 9031809090 Production Capacity 100sets/MonthProduct Description
GD-0609 Loss on Heating ASTM D6 ASTM D1754 TFOT Thin Film Oven for Asphaltic MaterialsTHIN FILM AND LOSS ON HEATING DETERMINATION (TFOT)
1. It is used for determining the loss in mass (exclusive of water) of oil and bituminous and the effect of heat and air on a film of semi-solid bituminous material.
2. The TFOT bitumen oven is for testing the effect on asphaltic materials of heating in an oven under prescribed conditions. The results are reported in terms of change in sample mass and/or changes in selected properties such as viscosity, penetration and ductility as evidenced by test data taken before and after the oven cycle.
3. The LOSS AND TFOT OVEN is suitable to test the quality loss after heating the road asphalt film. And also test the change of needle penetration, softening point, breaking point and ductility for asphalt residue as need to evaluate the aging resistance property of asphalt.
Features:
1. The outer shell is made of sheet steel. It equips a stainless steel working chamber on the top half. There is a observation window in the center. An illuminating lamp is equipped inside the chamber. Easy to observe the reading of thermometer inside the chamber during the test.
2. Heating device is equipped on the bottom of chamber. It adopts natural convection method to heat the air. The chamber can be heated uniformly by air channel on the top, bottom and back.
3. There are four turn plates for placing the specimen container on in the center of chamber. It can be rotated by a motor having a rate at 5.5RPM.
4. Intelligent temperature controller ensures the temperature being at 163ºC±0.5ºC as per standard test method.
Specifications:
1. Power supply: AC220V±10%,50Hz
2. Power: 2.5KW
3. Temperature of workroom: 163ºC±0.5ºC
4. Temperature control accuracy: ±0.5ºC
5. Rotate speed of turn plate: (5.5r±1r)/min
6. Test sample quantity: 4 pieces
7. Size of workroom: 450mm*450mm*510mm
8. Ambient temperature: 5ºC~50ºC
9. Relative humidity: ≤85%
