Programmable Constant Temperature and Humidity Test Chamber for Automobile Sensors
Ai Si Li (China) Test Equipment Co., Limited- Certification：CE, TUV, ISO
- Warranty：1 Year
- High Temperature：150 Degree C
- Indication Relolution of Temperature：0.1degree C
- Distribution Uniformity of Temperature：+,-2.0 Degree C
- Indication Relolution of Humidity：0.1% R.H
Base Info
- Model NO.：TH-150 (A~F) , TH-225 (A~F) , TH-408 (A~F)
- Distribution Uniformity of Humidity：+,- 3.0% R.H
- Approx. Weight (Kg)：180~320
- Transport Package：Standard Export Plywood Case
- Specification：CE, ISO
- Trademark：ASLi
- Origin：China
- HS Code：85141090
- Production Capacity：100 Sets,Month
Description
TH-225(A~F) TH-408 (A~F) Internal Dimension WxHxD (mm) 500x600x500 600x750x500 600x850x800 External Dimension WxHxD (cm) 1050x1750x1050 1200x1900x1150 1200x1950x1350 Temperature Range Low Temperature(A:25ºC B:0ºC C:-20ºC D:-40ºC E:-60ºC F:-70ºC)
High Temperature 150ºC Humidity Range 20%~98%R.H.(10%-98% R.H. / 5%-98% R.H ,is optiona , need Dehumidifier) Indication relolution / Distribution uniformity of temperature and humidity 0.1ºC; 0.1% R.H/±2.0ºC; ±3.0% R.H. Control Accuracy of Temperature and Humidity ±0.5ºC; ±2.5% R.H. Temperature Rising / Falling Velocity Temperature rising approx. 0.1~3.0ºC/min ;
temperature falling approx. 0.1~1.5ºC/min;
( Falling Min.1.5ºC/min is optional) Compressor French Tecumseh Brand, Germany Bizer Brand Power AC220V 1∮ 3 lines, 50/60HZ , AC380V 3∮ 5 lines , 50/60HZ Approx. Weight (Kg) 180 250 320
temperature and humidity test chamber Features:
1. Graceful appearance, circularly shaped body, surface treated with mist strips . Easy to operate, safe and reliable.
2. Rectangular double-paned viewing window for viewing sample under test, with interior light
3. Double-layer-insulated airtight doors, able to insulate the internal temperature effectively.
4. Water supply system that is externally connectable, convenient for refilling water into the humidifying pot and automatically recyclable.
5.French Tecumseh is used as compressor, with environment friendly refrigeration R23 or R404A
6. LCD display screen, capable of displaying the measured value as well as the set value and time.
7. The control unit has the functions of multiples segment program editing, with quick or ramp rates control of temperature and humidity.
8. Casters are provided for ease of mobility, with strong positioning screws.
Warranty: one year free warranty for whole set machine,lifelong time maintainance.
After-sale service: feedback within 8 hours after get the call or email.
Service:OEM service,Design service,Buyer lable service.
ASLi main test equipments:
Environmental chambers,temperature and humidity test chamber for automobile sensors,Thermal shock chamber,certified companies temperature and humidity test chamber, PCT /Hast chamber (Highly accelerated stress test chamber),ESS chamber, Walk in stability chamber,Vacuum oven,electrodynamic vibration shaker,mechanical shock tester,environmental combined vibration chamber,etc
