• Model NO.：TS-150-B
• Temperature Control Accuracy：+,- 0.5 Degree C
• Distribution Accuracy：+,- 2degree C
• Compressor：French "Tecumseh" Brand
• Viewing Window：Optional
• Test Hole：Dia. 50mm
• Transport Package：Wooden Case
• Specification：150 L
• Trademark：ASLi
• Origin：Guangdong, China
• HS Code：8514109000
• Production Capacity：300 Sets,Year

Temperature Impact Test Chamber Technical ParametersModel  TS-42(A~C) TS-80(A~C) TS-150(A~C) Internal Dimension
W*H*D ( mm) 400*350*350 500*400*400 600*500*500 External Dimension
W*H*D (mm) 1400*1800*1400 1550*1950*1550 1600*2000*1700 Temperature Range
of Testing zone Type A:-40 degree C
~+150degree C
(200degree C is Optional) Type B:-55degree C ~
+150degree C
(200degree C is Optional)   High temperature Range of Testing zone:
+60degree C~+150degree C(200degree C is Optional);
Low Temperature Range of Testing Zone: -10degree C~-40degree C/
-55degree C/-65degree C Exposure Time of
High/Low Temperature Exposure Time of High Temperature:+60degree C~+150degree C
(200degree C is Optional)  30Mins  Exposure Time of Low Temperature:-10degree C~Type A:-40degree C/
Type B -55degree C/ Type C -65degree C  30Mins Temperature of
Heat-Storing Slot/
Heating Time  RT~200degree C/About  45mins Temperature of
 Cool-storing Slot/
Cooling Time RT~-75degree C/ About 100mins Temperature
Recovery Time/
Conversion Time ≤5min/≤5sec  Control Accuracy /
Distribution Uniformity   ±0.5degree C/±2degree C Internal and Externa
l Material Material of the inner box is SUS 304# stainless steel,of the outer box  is stainless steel or SEE cold-rolled steel with paint coated. Insulation Material High temperature  resistant, high density, formate chlorine, ethyl acetum foam insulation materials  Mechanics P.I.D+S.S.R+ Micro-computer balanced temperature control system Cooling System Semi-hermetic double-stage compressor(water-cooled type) /Hermetic double-stage compressor (air-cooled type) Security Protection
 Devices Non-fuse breaker, high and low pressure protective switch of the compressor , refrigerator  high-pressure protective switch, failure warning system, electronic alarm Accessories Viewing window(special order) Compressor French "Tecumseh" Brand, Germany Bizer Brand Power AC220V 1 phase  3 lines,50/60HZ, AC380V 3phase  5 lines,50/60HZ Weight (Approx) 450 600                   750

For the package:
1. PP film first
2. Vacuum package
3. PP film again
4. 10mm thickness PU foam to avoid collision
5. stronged plywood case
6. Standard ASLI CASE MARK


Saftey device:
1. With no-fuse protection switch
2. Control system with phase sequence protection and low voltage electrical protection.
3. With over-heat protection switch.
4. Over load protection device for refrigeration compressor.
5. Refrigeration compressor high and low voltage protection switch.
6. Refrigeration compressor over oil pressure protection.


If you have any doubt about 5 Mins Recover High and Low Temperature Impact Test Chamber, please feel free to contact us.
