Competitive Price Device Speed and Accurate Measurement Portable Desktop Spectrophotometer
Beijing Samyon Instruments Co., Ltd.- After-sales Service：24hrs
- Warranty：1 Year
- Product Name：Spectrophotometer
- Mode：Single, Average
- Observing Angle：2,10 Degree
- Measuring Aperture：Dia8mm
Base Info
- Model NO.：SY8260
- Semiband Width：10nm
- Wavelength Interval：10nm
- Wavelength Range：400nm-700nm
- Transport Package：Carton
- Specification：SY268
- Trademark：SAMYON
- Origin：Cn
- HS Code：9031809090
- Production Capacity：999 Per Week
Description
Other Colorimetric IndexWI(ASTM E313,CIE/ISO,AATCC,Hunter), YI(ASTM D1925,ASTM 313), Metamerism Index MI, Staining Fastness, Color Fastness, Color Strength, Opacity 8° Glossiness,555 tone classification Observer Angle 2°/10° Illuminant D65,A,C,D50,D55,D75,F1,F2(CWF),F3,F4,F5,F6,F7(DLF),F8,F9,F10(TPL5),F11(TL84),F12(TL83/U30) Displayed Data Spectrogram/Values, Samples Chromaticity Values, Color Difference Values/Graph, PASS/FAIL Result, Color Simulation, Color Offset Measuring Time About 1.5s (Measure SCI & SCE about 3.2s) Repeatability Chromaticity value: MAV/SCI, within ΔE*ab 0.02 ( When a white calibration plate is measured 30 times at 5 second intervals after white calibration) Inter-instrument Error MAV/SCI, Within ΔE*ab 0.15
(Average for 12 BCRA Series II color tiles) Measurement Mode Single Measurement, Average Measurement(2-99times) Locating Method Camera Locating Dimension L*W*H=370X240X260mm Weight About 7.8kg Battery AC 24V, 3A Power adapter power supply Illuminant Life Span 5 years, more than 3 million times measurements Display 7-inch TFT color LCD, Capacitive Touch Screen Data Port USB, Bluetooth ®5.0, trigger switch interface Data Storage Standard 1000 Pcs, Sample 30000 Pcs Language Simplified Chinese, English, Traditional Chinese Operating Environment 0~40ºC, 0~85%RH (no condensing), Altitude < 2000m Storage Environment -20~50ºC, 0~85%RH (no condensing) Standard Accessory Power Adapter, USB Cable, User Guide, PC Software(Download from office website), White and Black Calibration Cavity, 8mm Aperture, 4mm Aperture Optional Accessory Micro Printer, Foot Switch, Rotating Bracket Notes Technical parameters are only for reference, subject to the actual sale of the product
