• Model NO.：YICT-800
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC380V
• Oil Cylinder Position：Top
• Inner Size(W*H*D)：1000*1000*800mm
• External Size(W*H*D)：2100*2280*1950mm
• Volume：800 Liters
• Temp. Range：-70degrees~ +150degrees(Ks)
• Temp. Rapid Change Range：-70degrees; -50degrs~ +85degrs
• Heating&Cooling Rate：3 Degrees,Min, 5degrees,Min, etc.
• Temp. Fluctuation：+,- 2 Degree
• Temp. Uniformity：+,-1.5degrees
• Interior Chamber Material：SUS#304 Stainless Steel Plate
• Exterior Chamber Material：Stainless Steel Plate + Powder Coated
• Transport Package：Strong Wood Carton
• Specification：Standard size
• Trademark：Yuanyao
• Origin：Dongguan, China(Mainland)
• HS Code：9032100000
• Production Capacity：10 Sets,Month

SpecificationModelYICT-225YICT-306YICT-408YICT-800YICT-1000Internal Dim.W×H×D(mm)500×750×600600×850×600600×850×8001000×1000×8001000×1000×1000External Dim.W×H×D(mm)1500×1930×15501600×2030×15501600×2030×17502100×2280×19502100×2280×1950Temperature Range -70ºC--  -150ºC(KS); -40ºC--   -150ºC(KL); +20ºC--  -150ºC(KR)Rapid Changes Temp.Range -70ºC;-50ºC-- +85ºC(KS),-40ºC; -20ºC--  +85ºC(KL),-20ºC; 0ºC-- +85ºC(KR)Heating & cooling rate3ºC/min,5ºC/min,8ºC/min,10ºC/min,15ºC/minFerformanceTemp.Constancy±2.0ºCTemp.Constancy±1.5ºCIndication Resolution0.01ºCHeat-up Time -70ºC--  -150ºC in 60min;  -40ºC--  -150ºC in 50min;   +20ºC--  -150ºC in 35minPull-down Time  +20ºC--  -70ºC in 70min;  +20ºC--  -40ºC in 55min;   +20ºC--  -20ºC in 35minMaterialExteriorStainless steel piate+powder CoatedInteriorSUS#304 stainless steel piateInsulationPU & Fiberglass woolSystemsCirulationSiroco fanHeatingHeater;stainless-gang Fin-type heat pipe heat pipe heating mode of air circulationCoolingAirtight compressor+vaporator fins+air-cooling condenser Other ComponentsVacuum glass inspection window, cable port(ø 60mm),control status indicator lights,chamber lamp,
experiment separation shelves(freely adjustable 2pcs) Sevey DevicesNo fuse overload protection, the compressor overheating,over-current, over-pressure,dry heat,
inside the over-temperature warning system Power Source[K.W.]AC 3Ψ 380V 60/50Hz
