• Model NO.：YVO-072
• Loading Method：Dynamic Load
• Display：Needle
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC380V
• Oil Cylinder Position：Under
• Inner Chamber Size(W*H*D)：400*450*400mm
• Exterior Chamber Size(W*H*D)：720*1160*560mm
• Temperature Range：R.T 25 Degree to 400 Degree
• Temperature Control Accuracy：+,-0.3degrees
• Temperature Uniformity：+,-1degrees
• Temperature Resolution：0.1degrees
• Vacuum Degree：Atmospheric Pressure to -98kpa
• Heat up Time：30minutes
• Power Supply：AC 3phase 380V 60,50Hz
• Controller：Omron E5az Controller
• Transport Package：Strong Plywood Carton
• Specification：Standard size
• Trademark：Yuanyao
• Origin：Dongguan, China(Mainland)
• HS Code：9031200000
• Production Capacity：20 Sets,Week

ModelYVO-072YVO-270YVO-480YVO-600YVO-720Inner chanber size W*H*D(mm)400*450*400600*900*500800*1000*6001000*1200*6001000*1200*600Exterior chanber size W*H*D(mm)720*1160*560930*1630*6701100*1720*7701160*1700*11601160*1500*1660Temperature RangeRoom temperature 25ºC ´ 200ºC(400ºC)PerformanceTemperature control accuracy ±0.3ºCTemperature uniformity±1ºCTemperature resolution0.1ºCHeat-up time30minutesMaterialExterior chamber material Cold rolled plate+Powder CoatedInterior chamber material SUS#304stainless steel plateInsulation PU & Fiberglass woolSystemWind Circulation Sirocco fanHeating system SUS#304 stainless steel high-speed heaterController Button type digital display controllerOther components cable port(60mm),control status indicator lights,loading shelves(2pcs for free)Safety Devices Overheating circuitbreaker, compressor overload protection, control system overload protection,
humidifying system overheating protection, breakdow indicator lightPower supply AC380V 60/50HzCustomizationCustomization of inner chamber size, temperature & humidity range etc.Vaccum agreeAt,ospheric pressure to -98Kpa

Product detail



Company profile













 If you want to know more about vacuum oven, please feel free to contact us.

Thanks for your reading !
