• Model NO.：HD-A513-2
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC220V
• Resolution：1,100,000
• Delivery Time：Within 15 Days
• Dimension (L*W*H)：790*510*1060 Mm
• Precision：< 0.5%
• Test Speed：12.7 Mm,Min
• Platen Parallelism：± 0.05 Mm
• Display Mode：LCD
• Compressed Space：500 Mm
• Ring Crush Sample：152×12.7 Mm
• Edge Crush Sample：25×100 Mm
• Transport Package：Strong Plywood Case
• Specification：ISO, ASTM, JIS
• Trademark：Haida
• Origin：Dongguan, China
• HS Code：9024800000
• Production Capacity：150 Set Per Month

Capacity  (Optional)10, 20, 50, 100, 200 kgResolution1/100,000Precision< 0.5%Operation ModeComputerDisplay ModeLCDPlaten100×100 mm or depending on the diameter of the flat crush sampleCompressed Space500 mmPlaten Parallelism± 0.05 mmRing Crush Sample152×12.7 mmEdge Crush Sample25×100 mmTest Speed12.7 mm/minDimension (L×W×H)790×510×1060 mmWeight Approx. 51 kgPower AC220V, 1.5A




The Introduction of Haida
Haida products are widely used in paper products, packaging, ink printing, adhesive tapes, bags, footwear, leather products, environment, toys, baby products, hardware, electronic products, plastic products, rubber products and other industries, and are applicable to all scientific research units, quality inspection institutions and academic fields. Our products meet UL, ASTM, JIS, GB,SO, TAPPI, EN, DIN, BS and other domestic and international standards.

Haida after-sale service:
1.Warranty: 1 year free warranty (Nature disaster and human damage expect)
2. Trouble figure out: Feedback with 2 hours after get the call, offer solution case and help to solve the problem in 8 hours.

Package information: PP film first, 10mm thickness foam ( between machine and plywood case), And then strong plywood case.
