• Model NO.：Thin Film Oven
• HS Code：9031809090
• Production Capacity：200PCS,Month

Basic Info.

Model NO. Thin Film Oven HS Code 9031809090 Production Capacity 200PCS/Month

Product Description

GD-0609 Asphalt Thin Film Oven ASTM D1754 Loss on Heating Test for Asphaltic Materials

 Preface:
The Loss-on-Heat Thin Film Oven(ASTM D1754) is design and made as per T0609-1993 and ASTM D1754 Standard Test Method for Effects of Heat and Air on Asphaltic Materials (Thin-Film Oven Test).
The Loss-on-Heat Thin Film Oven is suitable to test the quality loss after heating the road asphalt film. And also test the change of needle penetration, softening point, breaking point and ductility for asphalt residue as need to evaluate the aging resistance property of asphalt.



Features:
1. The outer shell is made of sheet steel. It equips a stainless steel working chamber on the top half. There is a observation window in the center. An illuminating lamp is equipped inside the chamber. Easy to observe the reading of thermometer inside the chamber during the test.
2. Heating device is equipped on the bottom of chamber. It adopts natural convection method to heat the air. The chamber can be heated uniformly by air channel on the top, bottom and back.
3. There are four turn plates for placing the specimen container on in the center of chamber. It can be rotated by a motor having a rate at 5.5RPM.
4. Intelligent temperature controller ensures the temperature being at 163ºC±0.5ºC as per standard test method.


Specifications:
1. Power supply: AC220V±10%,50Hz
2. Power: 2.5KW
3. Temperature of workroom: 163ºC±0.5ºC
4. Temperature control accuracy: ±0.5ºC
5. Rotate speed of turn plate: (5.5r±1r)/min
6. Test sample quantity: 4 pieces
7. Size of workroom: 450mm×450mm×510mm
8. Ambient temperature: 5ºC~50ºC
9. Relative humidity: ≤85%
