• Model NO.：GD-0722
• Transport Package：Wooden Case or Plywood
• Origin：China
• HS Code：9031809090
• Production Capacity：200PCS,Month

Basic Info.

Model NO. GD-0722 Transport Package Wooden Case or Plywood Origin China HS Code 9031809090 Production Capacity 200PCS/Month

Product Description

3000g Digital Centrifuge Extractor for ASTM D2172 Analysis of Asphalt Content by Centrifuge Extraction



Introduction:The 3000g Digital Centrifuge Extractor is designed and made as per T0722-1993 Standard Test Method for Bitumen Content of Bituminous Mixture by the Centrifuge Separation Method in Industrial Standard of People's Republic of China JTG E20-2011 and ASTM D2172 Specification and Test Methods for Bitumen and Bituminous Mixture for Highway Engineering.
The Bitumen Centrifuge Extractor  is suitable to determine bitumen content (bitumen-mineral aggregate ratio) in the bituminous mixture, which is made of viscous petroleum bitumen, by the centrifuge separation method.


Features:
1. Thicken aluminum alloy vessel. Stainless steel centrifugal shaft and instrument shell. Never rust .
2. Precise mechanical manufacturing technology. The rotation is stable and speed is fast.
3. Digital display timer.Multilevel start. Stable test operation.


Specifications:
1. Rated rotation speed: 3000r/min
2. Power supply:      AC(220±10%)V,50Hz
3. Volume:3000g
4. Timer: 40, 60, 80, 99(s)
5. Maximum power consumption:550W
6. Ambient temperature:10ºC~35ºC
7. Relative humidity:≤85%
8. Net weight:34.5Kg
9. Dimension: 430mm×410mm×445mm
