High Precision Drive Shaft Balancing Machine with Welding Machine (PHCW-100/200)

Shanghai Jianping Dynamic Balancing Machine Manufacturing Co., Ltd.
  • Weight：1000-2000Kg
  • Power Source：AC380V

Base Info

  • Model NO.：PHCW-100,200
  • Length：3600 Mm
  • Width：600 Mm
  • Height：1300 Mm
  • Gross Weight：1200 Kg
  • Transport Package：Packed in Fumigated Wood Box
  • Specification：ISO. CE. SGS
  • Trademark：Jp
  • Origin：Shanghai China
  • HS Code：9031100090
  • Production Capacity：1000 Sets,Month

Description

Basic Info.

Model NO. PHCW-100/200 Length 3600 Mm Width 600 Mm Height 1300 Mm Gross Weight 1200 Kg Transport Package Packed in Fumigated Wood Box Specification ISO. CE. SGS Trademark Jp Origin Shanghai China HS Code 9031100090 Production Capacity 1000 Sets/Month

Product Description

High precision Drive Shaft Balancing Machine (PHCW-100/200)



Production Description


Specially designed brackets transmit mechanical force with high rigidity
Durable and reliable sensor possesses high sensitivity
Permanent calibration brings high accuracy with a permission of large initial unbalance amount
Advanced electrical measuring system and friendly man-machine interface


Range of Application



This balancing machine is equiped with hard bearing structure. Electromechanical transducer adopts piezoelectric sensor Large output,small size, stable performance .Mainly used in the production and repair of all kinds drive shaft factories.With the advantages of high measuring speed, high precision,  easy to load and unload, Investment  at  low cost .it is an ideal device for shaft manufacturers and maintenance factories.



Special Features



The measuring unit employs JP-580B Electrical Measuring unit is a system of top function and precisionIt can be applied in all kinds of single/double plate and hard/soft bearing machines, and can be connected with different velocity and pressure sensors easily. The unit adopts industrial computer mainboard which equiped with 15-inch LCD screen and 1G Memory, Electric board 4G, Windows XP Operating System. Featuring with high running speed and reliabilitystrong dustproof and shakeproof ability, it is applicable to various industrial environments.


High Precision Drive Shaft Balancing Machine with Welding Machine (PHCW-100/200)

Factory outlook

High Precision Drive Shaft Balancing Machine with Welding Machine (PHCW-100/200)
Certificates

High Precision Drive Shaft Balancing Machine with Welding Machine (PHCW-100/200)
Production Parameters

Technical data at a glancePHCW-100/200
Mass Scope of Workpiece(kg)100/200
Max Diameter of Workpiece (mm)Ø130
Max Length of Workpiece (mm)2000
Rotation Speed of the Main Axis (r/min)-3200
Motor Power (KW)1.5(variable-frequency)
Min  Achievable  Residue Unbalance Amounte mar5g. mm/kg
