CNC Busbar Sawing Making Machine
Shanghai Trihope (PVT) Ltd- Saw Blade Diameter：405mm
- Minimum Allowable Sheet Length：40mm
- Max Cut Size (W*H)：200*20
- Min Allowable Sheet Dimension (W*H)：30*3
- Air Pressure：0.5-0.9 MPa
- Total Power：5.2kw
Base Info
- Model NO.：STI
- Main Machine Dimension L*W：2800*1200mm
- Total Weight：1500kg
- Cut Unit Motor Power：2.2kw
- Feeding Unit Servo Power：1.5kw
- Transport Package：Standard Packing
- Specification：2800*1200mm
- Trademark：STI
- Origin：Shandong
- Production Capacity：100 Sets ,Month
Description
Basic Info.
Model NO. STI Main Machine Dimension L*W 2800*1200mm Total Weight 1500kg Cut Unit Motor Power 2.2kw Feeding Unit Servo Power 1.5kw Transport Package Standard Packing Specification 2800*1200mm Trademark STI Origin Shandong Production Capacity 100 Sets /MonthProduct Description
CNC Busbar Sawing Machine
Main functions and features
- Busbar cut by saw blade can be beautiful section surface and smaller waste .
- Auto clamp with stroke 2000mm.
- Driven by spindle motor ,use high speed carbide disc blade .
- High precision ball screw ,linear guide rail ,servo motor for position of clamp and saw blade feeding .Assure high accuracy and working efficiency .
- Imported and branded components assure machine life and reliable quality .
- As per different width of busbar .Machine can be custoemerized .
