Pavement Slurry Seal Load Wheel Rolling Tester for Asphalt Mixture

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Asphalt：Emulsified Asphalt Slurry Seal Load Wheel Rolling
  • Emulsified Asphalt：Emulsified Asphalt Wheel Roller Compacting Testing
  • Wheel Rolling Test：Emulsifying Asphalt Loading Wheel Rolling Test Ins
  • Demulsibility Asphalt：Aaphalt Load Wheel Rolling Tester
  • Load Wheel Rolling：Pavement Slurry Seal Load Wheel Rolling Tester
  • Specification：ISO Certificate

Base Info

  • Model NO.：GD-0755
  • Trademark：GOLD
  • Origin：Chongqing of China
  • HS Code：9031809090
  • Production Capacity：100PCS,Month

Description

Basic Info.

Model NO. GD-0755 Trademark GOLD Origin Chongqing of China HS Code 9031809090 Production Capacity 100PCS/Month

Product Description

GD-0755 Pavement Slurry Seal Load Wheel Rolling Tester for Asphalt Mixture



Introduction:

The Emulsified Bitumen Load Wheel Rolling Tester is in accordance with People's Republic of China Ministry of Transportation standards JTG E20-2011 Standard Test Methods for Bitumen and Bituminous Mixtures for Highway Engineering in T 0755-2011 " Slurry mixture load wheel sticky sand test " provisions of the design and manufacture of it. Suitable for controlling the upper limit of the amount of asphalt in the slurry mixture, and determining the optimum asphalt content of slurry mixture with wet wheel wear test.



Features:

1. The Slurry Seal Load Wheel Rolling Tester is a floor structure, the structure design of the instrument, and test apparatus of the specifications of the size are accord with the requirement of T0755 standard. The design is novel, the structure is stable, and the use is convenient.

2. Mechanical transmission part design with safety protection device to prevent misidentification of the operator, safe and reliable.

3. Rolling frequency set by the operator in advance, when testing instrument automatic counting at work, until the count value is equal to the set point count stop, the instrument stop working.



Specifications:

1. Rolling frequency: 44 times / min ± 1 times / min

2. The crank radius: 152mm ± 2mm

3. Rubber wheel dimensions: diameter 76.5mm ± 1mm, width of 26.0mm ± 1.0mm

4. Rubber wheel hardness: Between HRC60 ~ HRC70

5. Rubber wheel loading weight: total weight of the car lay flat 56.7kg ± 0.5 kg

6. Test mode: There are 6.4mm, 12.7mm thickness of two kinds, according to the need to use the internal dimensions of 50mm*380mm

7. Sand frame: internal dimensions of 355.0mm*38.0mm*0.5mm

8. Steel plate: dimensions of 353 mm*36 mm*3 mm

9. Dimensions: 1400mm*260mm*450 mm

10. Power Supply: AC380V, 50Hz, 550W (three-phase four-wire system, with zero line)



Optional Accessories:

1. Platform balance: Weighing 100g, the sense of it not more than 0.5 kg

2. Balance: Weighing 2000g, the sense of it not more than 1g

3. Oven: With forced ventilation, temperature can be controlled at (60 ± 3) ºC
