• Model NO.：Q-100B
• Accuracy Grade：1
• Load Way：Without
• Loading Method：Dynamic Load
• Display：Digital
• Control：Electric
• Weight：0-100Kg
• Power Source：AC220V
• Max Cutting Capacity：Diameter 80mm
• Cooling Method：Outside Cooling System
• Cutting Wheels Size：250X2.5X32mm
• Power ：2.2kw
• Spindle Speed：2800rpm
• Transport Package：Standard Exporting Plywood Case
• Specification：400*730*310mm
• Trademark：OBT
• Origin：China
• HS Code：9024109000
• Production Capacity：100 PCS,Month

Basic Info.

Model NO. Q-100B Accuracy Grade 1 Load Way Without Loading Method Dynamic Load Display Digital Control Electric Weight 0-100Kg Power Source AC220V Max Cutting Capacity Diameter 80mm Cooling Method Outside Cooling System Cutting Wheels Size 250X2.5X32mm Power  2.2kw Spindle Speed 2800rpm Transport Package Standard Exporting Plywood Case Specification 400*730*310mm Trademark OBT Origin China HS Code 9024109000 Production Capacity 100 PCS/Month

Product Description

Q-80Z metallographic sample cutting machine

1.Application and Feature of cutting  Machine
Model Q-100Bmanual / automatic metallographic specimen cutting machine is equipped with big cutting room and movable T-shape work table. Therefore this machine has the ability of cutting rectangle and large specimens. Also the equipped separate type vice is very convenient for operator to clamp various heterotypic work pieces. Various cutting data can be displayed on high definition backlight type LCD screen.  Manual cutting and automatic cutting means can be switched at will. Large cutting chamber, tempered glass observing window and it is equipped with 60L cooling liquid water tank. Non-burning loss swing type cutting means which improved the cutting quality Automatic withdraw function after cutting is finished, bidirectional feeding means increase the length of deep cutting.

2. Main Specifications:

Model	Q-100B
Display	LCD with high resolution back lit dot matrix
cutting disc speed	2100rpm
Cutting diameter	100mm
max moving travel	125mm
max working table travel	275mm
Cutting disc specification	350 ×2.5 ×32mm
Motor	3.3kw
Feed speed	1-10mm/min
power supply	three phases, 380V, 50Hz
Net weight	220Kg
Dimension	900 x 850 x 620mm
