• Model NO.：PHCW-100,200F
• Length：3600 Mm
• Width：600 Mm
• Height：1300 Mm
• Gross Weight：1200 Kg
• Place of Origin：Shanghai, China
• Brand Name：Jp
• Delivery：25days
• Transport Package：Fumigated Wood Box
• Specification：ISO. CE. SGS
• Trademark：JP
• Origin：Shanghai China
• HS Code：90311000
• Production Capacity：1000 Sets,Month

Basic Info.

Model NO. PHCW-100/200F Length 3600 Mm Width 600 Mm Height 1300 Mm Gross Weight 1200 Kg Place of Origin Shanghai, China Brand Name Jp Delivery 25days Transport Package Fumigated Wood Box Specification ISO. CE. SGS Trademark JP Origin Shanghai China HS Code 90311000 Production Capacity 1000 Sets/Month

Product Description

Transmission shaft balancing machine with welder (PHCW-1000)

Production Description:
Specially designed brackets transmit mechanical force with high rigidity
Durable and reliable sensor possesses high sensitivity
Permanent calibration brings high accuracy with a permission of large initial unbalance amount
Advanced electrical measuring system and friendly man-machine interface

Special Features:
The measuring unit employs JP-580 Electrical Measuring unit is a system of top function and precision. It can be applied in all kinds of single/double plate and hard/soft bearing machines, and can be connected with different velocity and pressure sensors easily. The unit adopts industrial computer made in Yanxiang Industry Co, which equiped with 17-inch LCD screen and Windows XP Operating System. Featuring with high running speed and reliabilitystrong dustproof and shakeproof ability, it is applicable to various industrial environments

Range of Application:
This balancing machine is equiped with hard bearing structure. Electromechanical transducer adopts piezoelectric sensor Large output, small size, stable performance. Mainly used in the production and repair of all kinds drive shaft factories. With the advantages of high measuring speed, high precision, easy to load and unload, Investment at low cost. It is an ideal device for shaft manufacturers and maintenance factories.
Production Parameters:

Technical data at a glance	PHCW-1000/2000
Max Mass of Workpiece (kg)	1000/2000
Effective length of workpiece(mm)	3000
Max Diameter of Workpiece(mm)	Φ400
Shaft tube diameter of workpiece(mm)	Φ300
Balancing speed(mm)	600-1200/450-1200
Spindle Speed(r/min)	410,750 stepless speed regulation
Motor Power(KW)	3 frequency conversion
Universal joint torque(N.M)	300
Min Achievable Residual Unbalance Amount(e mar )	≤5g.mm/kg
A reduced rate (%)	≥85

After Sale Service:
Professional engineer and application specialists respond to your requests efficiently
Online via SKYPE MSN; Also through mail, voice phone message and fax if network is not accessible for customer
Follow up the case, record the entire process. Solution will be provide with 24 hours
Meanwhile, the problem complaint will be reported to QC department
QC will find defect from which department, who is in charge to identify responsibility
Collecting and record customer respond, suggestion, requirement


Warranty period:
Life-time warranty. Any problem caused by our party within one year from the date of shipment, we will provide free spare parts for the repairment. After one year, we can provide the spare parts, but the user should pay for the related cost, including cost of the spare parts, delivery cost etc.

About Us
Shanghai Jianping Dynamic Balancing Machine Manufacturing Co., Ltd. Is a professional manufacturer of dynamic balancing machine, which is high-tech technology enterprises of Optical-electro-mechanical Integration,
Factory:shjpbalancer.en.made-in-china.com
There are ten series and more than 40 models of balancing machines, including belt drive balancing machine, universal joint drive balancing machine, vertical balancing machine, cross flow fan blade balancing machine, drive shaft balancing machine, self-drive balancing machine and auto-positioning balancing machine, two-plane axial flow balancing machine, smart balancer, automatic balancing machine, soft bearing balancing machine, manual milling machine etc.
