• Model NO.：STSCJ-300
• Accuracy Grade：1
• Load Way：Electronic Load
• Loading Method：Dynamic Load
• Display：Digital
• Control：Manual Control
• Weight：1500
• Power Source：AC380V
• Oil Cylinder Position：Under
• Max. Testing Power：300kn
• Measuring Range：12-300kn
• Indication Error：<1%
• Loading Precision：10n
• Loading Speed：100-5000n,S
• Lead Screw Stroke：100mm
• Max. Distance Between The Left and The R：850mm
• Power：AC220V 1.0kw
• Transport Package：Wooden Case
• Specification：950x400x1160mm
• Trademark：SHTG
• Origin：China
• HS Code：9031809090
• Production Capacity：100PCS,Month

Basic Info.

Model NO. STSCJ-300 Accuracy Grade 1 Load Way Electronic Load Loading Method Dynamic Load Display Digital Control Manual Control Weight 1500 Power Source AC380V Oil Cylinder Position Under Max. Testing Power 300kn Measuring Range 12-300kn Indication Error <1% Loading Precision 10n Loading Speed 100-5000n/S Lead Screw Stroke 100mm Max. Distance Between The Left and The R 850mm Power AC220V 1.0kw Transport Package Wooden Case Specification 950x400x1160mm Trademark SHTG Origin China HS Code 9031809090 Production Capacity 100PCS/Month

Product Description

STSCJ-300 Microcomputer Controlled Tensile Stress Relaxation Testing Machine

Features:
1. Relation curves between surplus testing power(or LESR) and the time are available.
2. Specimen Stress relaxation of 1000 hours could be calculated.
3. Loading speed 100-5000N/S, speed is variable.
4. Automatically calculate stress relaxation characteristic(such as stress relaxation rate)
and print complete testing report.
5. Load and displacement are calibrated by numbers.
6. Test results are saved and records of testing process could be consulted.
7. The system automatically adjusts coordinates under different testing condition.
 Complete curve is indicated during test procedure.
8. Test parameters can be automatically saved, assigned out and re-set.
9. Data collection: You can use the mouse to collect data from the curve after the test
completed.
10. Stainless steel housing.

Technical parameters:


Max. testing power	300kN
Measuring range	12-300kN
Indication error	<1%
Loading precision	10N
Loading speed	100-5000N/S
Lead screw stroke	100mm
Max. distance between the left and the right clamps	850mm
Power	AC220V±10%   1.0kW
