Fully Automatic Softening Point Analyzer for Bitumen/ Asphalt

Chongqing Gold Mechanical & Electrical Equipment Co., Ltd.
  • Testee：Bitumen in 30 to 157centigrade
  • Rference Standard：ASTM D36
  • Operation Mode：Full-Automatic
  • Test Method：Ring-and-Ball Apparatus Immersed in Distilled Wat
  • Stirrer：Electromagnetic Stirring,The Speed Is Stepless Adj
  • Reference Standard：ASTM D36, IP58

Base Info

  • Model NO.：GD-2806I
  • Effective Volume of Flask：1000ml
  • Transport Package：Standard Wooden Case
  • Trademark：GOLD
  • Origin：Chongqing of China
  • HS Code：9031809090
  • Production Capacity：100PCS,Month

Description

Power supplyAC 220V (-5%~+10%), 50 Hz; Measurement range32 ºC~160 ºC.
   (1) Heating medium: distilled water(softening point under 80 ºC)
   (2) Heating medium: glycerin (softening point over 80 ºC)
 Temperature resolution0.01ºCStirrerelectromagnetic stirring,the speed is stepless adjustable. Heating rateSelf adjusting to (5.0±0.5)ºC/ min after 3 minutes.Display and printLCD screen to displays the result. Printed by printer Heating power1400WPC portRS-232C communication portEffective volume of flask1000mlTest conditionroom temperature is lower than 35ºC and stable.
 No air convection.
 Relative humidity≤ 85%Overall power consumption≤ 1500WTest sample 2 samples
