• Model NO.：YAW-300C
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC220V
• Accuracy：1 Class
• Compression Stroke：80mm
• Distance Between Upper/Lower Plate：220mm
• Plate Diameter：Dia 140mm
• Transport Package：Standard Shipping Case
• Trademark：Hensgrand or OEM
• Origin：Jinan, Shandong, China
• HS Code：9024800000
• Production Capacity：500 Sets,Month

ModelYAW-100GYAW-200GYAW-300GMax.Load100KN200KN300KNTest class1class Control wayConstant stress and constant strain,
constant displacement closed loop control modeLoad range2%-100%FSLoad accuracyBetter than ≤±1%Displacement value accuracyBetter than ±0.5%Displacement value resolution0.005mmDisplacement rate control adjusting range0.005~25mm/minEffective compression stroke80mmMax distance between upper and lower plate220mmCentral distance between the two columns350mmSize of upper and lower platenDia 140mmPower220V, 1.5kW, 50Hz4. Configuration:
4.1 High strength main unit -1 set
4.1.1High precision arc synchronous gear system--1set
4.1.2 High efficient speed reducer--1set
4.1.3High precision ball screw vice--1set
4.1.4 Special compression fixture-- 1set
4.15 Dustproof cover--1 set
4.2 measurement and control system--1set
4.2.1High-precision photoelectric encoder-1pc
4.2.2 AC servo control system--1 set
4.2.3AC servo adjusting speed motor--1set
4.2.4 High precision spoke type sensor--1pc
4.2.5 LENOVO computer--1set
4.2.6 HPA4 printer--1set
4.2.7Special measurement and control system--1set
4.2.8 Special software under Windows operating environment---1set
