• Model NO.：HTPV-09A
• Loading Method：Without
• Display：Computer
• Control：Computer Control
• Weight：500-1000Kg
• Power Source：AC220V
• Oil Cylinder Position：Without
• Name：PV Module Hail Impact Tester
• Standard：IEC61215-2:2016,IEC61646
• Air Pressure：6-8bar
• Transport Package：Wood Case
• Specification：IEC61215, UL1703
• Trademark：HOTOTECH
• Origin：Dongguan, Guangdong Province
• HS Code：9013809000
• Production Capacity：100 Sets Per Month

Basic Info.

Model NO. HTPV-09A Loading Method Without Display Computer Control Computer Control Weight 500-1000Kg Power Source AC220V Oil Cylinder Position Without Name PV Module Hail Impact Tester Standard IEC61215-2:2016,IEC61646 Air Pressure 6-8bar Transport Package Wood Case Specification IEC61215, UL1703 Trademark HOTOTECH Origin Dongguan, Guangdong Province HS Code 9013809000 Production Capacity 100 Sets Per Month

Product Description

PV module hail impact tester

PV module hail impact tester Standard
according to IEC61215,UL1703

PV module hail impact tester Purpose
use to verification module resistance impact ability , artifical hockey use to simulate hail , and to the
constant speed impact component , simulate hail climate against component effect .

PV module hail impact tester Parameter
1.Effective impact area:1200 * 2100mm
2.Standard hail diameter:25mm±5%
3.Standard hail mass:7.53g±5%
4.Hail setting speed:23.0m/s±5%
5.Speed measurement accurate :±2%
6.Hail mass measurement accurate:±2%
7.Pneumatic shoot system
8.Main function:
8.1,Chinese operate interface,setting impact position ,impact speed , hail reference ,time etc reference.
8.2,two dimension stepping driving system , the interface can setting the displacement
8.3,can programme control automatic being multipoint impact test
8.4,the hail shoot speed through compression air's pressure adjust
8.5,light spot fixed point collimation function ,convenience to ensure impact point position

Company introduction
  Dongguan Hong Tu Instrument Co.,Ltd specializes in developing and producing PV module testing machines and our company established in 2006 year , we have firm connections and full cooperation from China's National Third-Party Quality Inspection and Notarization Center on producing and developing high-precidion testing machines
  We treasure the value of good quality , reasonable price and efficient service with cusotmer satisfaction . we expert ourselves in providing our customers the best suitable testing designs and high quality testing machines to make you the utmost profit


Customer visit


Testing machine package show
