GDYZ-11 MOV tester for lightning protection device
HV Hipot Electric Co., Ltd.- Type：Universal Testing Machine
- Accuracy Grade：1
- Load Way：Electronic Load
- Loading Method：Dynamic Load
- Display：Digital
- Control：Computer Control
Base Info
- Model NO.：GDYZ-11
- Weight：0-100Kg
- Power Source：AC220V
- Voltage Measurement range：1.00~10.00kV
- Accuracy of constant current：1.00mA±0.05mA
- Voltage measurement accuracy：≤±0.5%±1 digit
- Transport Package：Standard Export Wooden Box
- Specification：ISO, SGS
- Trademark：HV Hipot
- Origin：Wuhan, China
- Production Capacity：5000set,Year
Description
Voltage Measurement range
1.00~10.00kV
Accuracy of constant current
1.00mA±0.05mA
Voltage measurement accuracy
≤±0.5%±1 digit
Leakage current measurement
leakage current is measured at voltage U1mA*75%
Error of constant current
≤1%±1 digit
Measurement range of leakage current
0~100.0μA
Measurement error of leakage current
10% or 2μA (the larger value is taken)
Size
420*150*300mm
Weight
5kg
