• Model NO.：0PS9000S
• Loading Method：Dynamic Load
• Display：Digital
• Control：Computer Control
• Weight：0-100Kg
• Power Source：AC380V
• Oil Cylinder Position：Customized
• Transport Package：Package Box
• Specification：480*280*230
• Trademark：STI
• Origin：Shanghai, China
• Production Capacity：20 Unit, Month

Basic Info.

Model NO. 0PS9000S Loading Method Dynamic Load Display Digital Control Computer Control Weight 0-100Kg Power Source AC380V Oil Cylinder Position Customized Transport Package Package Box Specification 480*280*230 Trademark STI Origin Shanghai, China Production Capacity 20 Unit/ Month

Product Description

OPS9000S Hand-held Enamelled wire needle hole detector For Wire tester

Summary
1.  Executive standard: IEC60851  GB/T4074.5
2.  Testing Range: Various Specifications of Enamel- covering , film covering round line and flat wire
3.  Small size, Light weight, Easy to carry and simple operation
4.  Charge once for ten hours
5.  The test voltage of 350v.500v,750v, 1000v, 1500v, 2000v,2500v and 3000v can be chosen
6.  The voltage is the smoothness DC voltage through filtering

Main Technical Parameters

Test Voltage error	< 5%
Steady state short-circuit current	25±5 uA
Count Frequency when bare with contacts	500±10n/mim
Voltage drop caused by 50MΩ defect resistance	< 75%
Response time for the defected counting circuit	5 ± 1mS
Work environment	Temperature 0-40ºC andrelativehumidity ≤ 75%
External power	AC220V ± 5% 50Hz
Consumed power	≤ 50W
Dimension of host	480L* 280W*230H
Weight	560g
