• Model NO.：HRS-45T
• Testing Before Delivery：Yes
• Transport Package：Standard Exporting Wooden Package
• Trademark：DahoMeter
• Origin：Dongguan, China
• Production Capacity：300 Sets,Month

Basic Info.

Model NO. HRS-45T Testing Before Delivery Yes Transport Package Standard Exporting Wooden Package Trademark DahoMeter Origin Dongguan, China Production Capacity 300 Sets/Month

Product Description

HRS-45T Digital Display Superficial Rockwell Hardness Tester 0.1HR Surface Hardness Meter


Introduction
Model HRS-45T is used to determine the surface Rockwell hardness of ferrous metals, alloy steels, hard alloys and metals after nitriding, cyanidation, carburizing, electroplating and other surface treatments.


Main Feature
Digital display, direct reading of digital display, no artificial reading error, resolution up to 0.1HR, and can convert hardness value, mechanical manual testing process, no electrical control, precision oil pressure buffer, adjustable loading speed. Accuracy conforms to GB/T230.2, ISO6508-2 and American ASTM18 standards.



Main Technical Specifications

Model	HRS-45T
Measuring range	70-94HRN, 42-86HR30N, 20-77HR45N, 67-93HR15T, 29-82HR30T, 10-72HR45T
Maximum allowable height of the test piece	170 mm
Distance from the center of the indenter to the machine wall	135mm
Hardness resolution	0.1HR
Dimensions	466 x 238 x 630 mm
Weight	about 65kg

Standard Configuration
Large platform: 1 set.
Small platform: 1 set.
V-type test bench: 1 set.
116 steel ball indenter: 1 set.
Diamond indenter: 1 set.
Model HRS-150T : Standard Rockwell hardness block: 5 pcs.
Model HRS-45T : Standard surface Rockwell hardness block: 4 pcs.



About  Company

We, Dongguan Hongtuo Instrument Co., Ltd, a China based company, are pleased to introduce ourselves as a notable testing equipments and machines manufacturer.Our company was established in the year 2000 with two primarily motto, which includes complete client satisfaction and to reach top-most position in the international market. The exceptional quality of our products like Gold Tester,Gold Testing Machine,Density Meter,Universal Tensile Testing Machine,Climatic Chamber,Melt Flow Index Tester,Charpy Impact Testing Machine,Tap Density Tester,Abrasion Tester,Ultrasonic Flaw Detector,Surface Roughness Tester and other Laboratory Testing Equipment, etc. is our company's USP.




Certification

FAQ
1.Quality Insurance
We guarantee this instrument for 1 year and life-long maintenance. We will be responsible for fixing or replacing the instrument if quality issue was arisen,the service is excluding if the machine is breakdown caused by following reasons: (1) Wrong operation; (2) Fixed or refitted personally; (3) The machine itself is not the reason caused breakdown; (4)Applying the machine under the serious conditions.such as high temperature,moist, corrosive gas,or vibration. (5)Move or transportation as soon as installed. (6)Consumables and easy-loss components. (7)Natural disaster

2.After-sales Service
a.If errors occur,please refer to the troubleshooting tips of the instruction manual. b.Please contact with our after-sales service department or distributor in time if can't clear fault.

3.Are we manufacturer made copy product or original product?
We are the original manufacturer.

4.Why choose us?
We deep understood what's you need is not only product,but also all-around service support,especially for technical instruction and after-sales service. a.We have been specialized in this field since 2002. b.Professional researching and technology team. c.Customer service team.

5.Can you offer quality certification?
Yes.We can offer quality certification issued by our quality control department with free of charge.or issued by third-party international inspection organizations with extra charge.

6.Can you do the calibration and testing before handover the goods?
Yes.We do testing and calibration for every product before delivery.
