100ton Computer Display Tensile Test Instrument
Jinan Kason Testing Equipment Co., Ltd.- Type：Material Testing Machine
- Maxcapacity：<1000KN
- Accuracy Grade：1
- Load Way：Mechanical Load
- Loading Method：Static Load
- Display：Computer
Base Info
- Model NO.：WEW-1000D
- Control：Computer Control
- Weight：1000-2000Kg
- Power Source：AC380V
- Oil Cylinder Position：Under
- Product Name：Tensile Test Instrument
- Application：Tensile Compression Bending Test
- Test Accuracy：1 Class
- Structure：6 Column
- Max.Piston Stroke：250mm
- Protection Net：with Overload, Overcurrent and Protection Net
- Max Load：100kn,300kn,600kn,1000kn
- Power Supply：3-Phase,AC380V, 50Hz
- Clamping Method：Hydraulic Clamp
- Certificate：Ce ISO
- Transport Package：Standard Exporting Plywood Case
- Specification：2200KG
- Trademark：HST
- Origin：China
- HS Code：9031809090
- Production Capacity：100sets,Momth
Description
WEW-600DWEW-1000D Max load (kN) 300 600 1000 Structure 6 column Control way loading process manual control,computer automatic data dealing Load accuracy ≤±1% or ≤± 0.5% Load range 2%-100%FS or 0.4%-100%FS Load resolution 1/300000 Deformation Measurement Range 2%~100%FS Deformation accuracy ≤±1%/± 0.5% Displacement resolution 0.01mm Displacement error ≤±0.5% Max.piston stroke 250mm Max. tension test space 600 mm 500 mm 500mm Max compression test space 750 mm 650 mm 650mm Oil cylinder moving speed 140 mm/min 90 mm/min 50 mm/min Crosshead moving speed 200mm/min 150mm/min 120mm/min Effective space between columns 420mm 475mm 525mm Round specimen clamping range Φ10-Φ32mm Φ13-Φ40mm Φ13-Φ40mm Flat specimen clamping range 0-15mm Clamping method Hydraulic clamp Clamp height 70mm 90mm 90mm Clamping width 75mm 80mm 80mm Compression plate size φ160mm Bending roller distance 450mm Width of bending rollers 120mm Power supply 3-phase,AC380V, 50Hz(can be customized)
