Rubber Mooney Viscosity Tester/Mooney Viscometer/Rubber Mooney Viscosity Meter
Dongguan Hongjin Test Instrument Co., Ltd.- After-sales Service:Lifetime Maintenance
- Warranty:1 Year
- Type:Universal Testing Machine
- Loading Method:Static Load
- Control:Computer Control
- Weight:0-100Kg
Base Info
- Model NO.:HJ-56
- Power Source:AC220V
- Torque Range:0-100 Mooney Value
- Test Pressure:11.5kn Positive or Negative 0.5kn
- Gas Distribution:0.45-0.6MPa
- Power Supply:220V 1kVA
- Machine Size About:660X570X1300mm
- Machine Weight About:210kg
- Transport Package:Fumigation-Free Standard Export Wooden Box
- Trademark:Hongjin
- Origin:China
- Production Capacity:1000 Sets, Month
Description
Basic Info.
Model NO. HJ-56 Power Source AC220V Torque Range 0-100 Mooney Value Test Pressure 11.5kn Positive or Negative 0.5kn Gas Distribution 0.45-0.6MPa Power Supply 220V 1kVA Machine Size About 660X570X1300mm Machine Weight About 210kg Transport Package Fumigation-Free Standard Export Wooden Box Trademark Hongjin Origin China Production Capacity 1000 Sets/ MonthProduct Description
This machine complies with the requirements of GB/T 1232 "Determination of Mooney Viscosity of Unvulcanized Rubber", GB/T1233 "Determination of Mooney Viscometer Method of Initial Vulcanization Properties of Rubber Compounds" and ISO289, ISO667 and other standards. The viscosity, scorch and vulcanization index of the rubber compound. Microcomputer control, data display, automatic calibration, it is an ideal experimental instrument for rubber industry and scientific research units. Imported intelligent digital temperature control instrument is adopted, which is easy to adjust and set, and has a wide temperature control range. The microcomputer adopts imported chips, with high reliability, and all data can be automatically calculated and printed.Temperature measurement range | 0--200ºC |
Temperature measurement accuracy | ≤±0.3ºC |
Control precision | ≤±0.3ºC |
Temperature resolution | 0.1ºCE |
Torque range | 0-100 Mooney value |
Calibration accuracy | 100±0.5 Mooney value |
Rotor speed | 2±0.02 r/min |
Ambient temperature | 0--35 ºC |
Relative humidity | <80 |
Test pressure | 11.5KN ±0.5KN |
Gas distribution | 0.45-0.6MPA |
Power supply | 220V 1KVA |
Machine size | About 660×570×1300mm |
Machine weight | About 210Kg |
