• Model NO.：EL23 series
• HS Code：90248000
• Production Capacity：5000 Sets,Month

Basic Info.

Model NO. EL23 series HS Code 90248000 Production Capacity 5000 Sets/Month

Product Description

Riffle box/ Sample divider/ Sample splitter

STANDARD: EN 932-1, 932-2 - ASTM C702

    For the rapid preparation of samples, i.e. division into two representative portions. Detailed below is a range of
dividers, each constructed of heavy gauge sheet metal, with particular attention given to reinforcement of the partitions to maintain the accuracy of the slot dimensions.
    The units offered are supplied in a range of sizes from 7 mm to 64 mm slots.

Model	Max. size sample (mm) BS                           EN	Slot width (mm)	No. of slots	Approx. capacity (kg)
EL23-3000	4.5                          3.5	7	12	0.3
EL23-3050	8.5                          6.5	13	12	2.0
EL23-3070	10.0                        7.5	15	12	2.0
EL23-3100	12.5                        9.5	19	10	4.0
EL23-3150	16.5                       12.5	25	10	4.0
EL23-3170	20.0                         15	30	10	4.0
EL23-3200	25.0                         19	38	8	11.0
EL23-3300	33.0                          25	50	8	14.0
EL23-3350	42.5                          32	64	8	18.0
