• Model NO.：HST-6019
• Accuracy Grade：1
• Load Way：Mechanical Load
• Loading Method：Static Load
• Display：Computer
• Control：Computer Control
• Weight：100-500Kg
• Power Source：AC 380V ,220V
• Oil Cylinder Position：No
• Color：Gray, White , Blue,Green or Customized
• Temperature Fluctuation：0.1c
• Temperature Resolution：0.1c
• Time Setting：2-120min
• Transport Package：Standard Sea Shipping Case
• Specification：640*580*1300mm
• Trademark：HST or OEM
• Origin：China
• HS Code：9024800000
• Production Capacity：500 Sets,Month

Basic Info.

Model NO. HST-6019 Accuracy Grade 1 Load Way Mechanical Load Loading Method Static Load Display Computer Control Computer Control Weight 100-500Kg Power Source AC 380V /220V Oil Cylinder Position No Color Gray/ White / Blue/Green or Customized Temperature Fluctuation 0.1c Temperature Resolution 0.1c Time Setting 2-120min Transport Package Standard Sea Shipping Case Specification 640*580*1300mm Trademark HST or OEM Origin China HS Code 9024800000 Production Capacity 500 Sets/Month

Product Description

HST-6019 Computer Control No Rotor Rheometer Rubber Testing Equipment
Application:
The machine is applied to determine the characteristics of vulcanized rubber, widely used in rubber processing industry, rubber quality control and basic research rubber.

Features:
1. This non rotor rheometer is really confined mold cavity, and the United States Alpha (formerly Monsanto) has done. Repeatability, and test data comparable with the Alpha. At the international leading position in the same industry.
2. The non rotor rheometer development platform based on large databases, temperature control devices using the software to directly control and collection and processing. Instrument to overcome the general curing temperature of the shortcomings of using temperature controller (accuracy poor).
3. This instrument has statistics, analysis, storage and comparison functions. Humanized design, easy to operate
4.Have the function of comparison and amplification carve
5.Computer controlled,application WINDOWS series operating system platform.

Corresponding standards:
According with GB/T16584"rubber- no rotor rheometer to measure the characteristics of vulcanized" ISO6502.

Technical parameters:

Model	HST-6019 Computer Type No Rotor Rheometer
Temperature	room temperature to 200 Centigrade
Heating rate	in 10 minutes from room temperature to 200°C
Temperature fluctuation	±0.1°C
Temperature resolution	0.1°C
Time setting	2-120min
Torque range	5N.M-10N.M
Rotor swing angle	±0.5
Consumed power	800W
Power	50HZ, 220V±10%
Out size	640mm×580mm×1300mm
Weight	210kg
